The CubeNode ETH is a compact networking adapter by CubePilot, designed to add 10/100 Mbps Ethernet connectivity to Cube flight controllers lacking native support. Powered by dual-core Arm® Cortex® M7 and M4 processors, it runs at up to 480 MHz and 240 MHz respectively. With support for PPP over serial, the CubeNode ETH enables up to 12 Mbps bi-directional networking, facilitating transmission of MAVLink, CAN and other protocols—all through a single serial port without sacrificing additional telemetry or data interfaces. Ideal for UAV builds requiring robust, lightweight network integration.

Features

High-Performance Dual-Core MCU
Features Arm® Cortex®-M7 (480 MHz, double-precision FPU) paired with Cortex®-M4 (240 MHz, single-precision FPU), equipped with DSP instructions and MPU for secure, efficient processing.
Lightweight, Compact Design
Small PCB module (approx. 28 × 11 × 10 mm) weighing just ~2.7 g (7.3 g with cables).
Robust Memory Profile
Dual-bank 2 MB Flash and 1 MB RAM (192 KB TCM, 864 KB SRAM, 4 KB backup SRAM) enabling firmware upgrades and buffer handling.
Ethernet via PPP Protocol
Connects over one serial port (with flow control) to achieve network speeds up to 12 Mbps. Supports MAVLink, CAN, TCP/UDP traffic. Works out-of-box with CubeOrange+ and CubeRed on ArduPilot ≥ 4.5.

Specifications

Parameter	Details
MPN	CP‑06328
Manufacturer	CubePilot
Processors	Cortex‑M7 (480 MHz, double‑precision FPU), Cortex‑M4 (240 MHz)
Flash Memory	2 MB dual-bank
RAM	Total 1 MB (192 KB TCM + 864 KB SRAM + 4 KB backup)

Disclaimer: Product details are provided for reference only. Please verify all specifications and features with the official source, as information may change or vary.

Cube Pilot

CubeNode ETH – Ethernet Adapter for CubePilot Flight Controllers

The Cube Orange Plus AutoPilot with ADS-B Carrier Board for UAV in India

Pixhawk Mini Carrier Board for The Cube Autopilot in India
