Description
The APC 10×5E Thin Electric Propeller is a lightweight two-blade propeller designed specifically for electric-powered aircraft. Its 10-inch diameter and 5-inch pitch provide a balanced combination of propeller area and forward pitch for suitable electric propulsion setups.The propeller uses APC’s thin electric design with a reinforced composite construction. The relatively thin blade profile helps reduce rotating mass and aerodynamic drag while maintaining stiffness and pitch stability during operation.
Features
- 10-inch propeller diameter
- 5-inch pitch
- Two-blade configuration
- Thin Electric design
- Designed specifically for electric motors
- Lightweight composite construction
- Reinforced material for improved blade stiffness
- Designed to maintain consistent pitch during operation
- Reduced rotating mass
- Aerodynamically optimized thin blade profile
- Suitable for electric RC aircraft and UAV applications
- EP version provides reverse/CCW rotation for matched propulsion configurations.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | APC |
| Product Type | Thin Electric Propeller |
| Size | 10 × 5 inch |
| Diameter | 10 in / 254 mm |
| Pitch | 5 in / 127 mm |
| Number of Blades | 2 |
| Hub Diameter | 0.80 in / 20.32 mm |
| Hub Thickness | 0.38 in / 9.65 mm |
| Shaft / Bore Diameter | 1/4 in / 6.35 mm |
| Weight | 0.71 oz / approx. 20.1 g |
| Material | Reinforced nylon composite |
| Rotation – 10×5E | Standard rotation |
| Rotation – 10×5EP | Reverse / CCW |
| Application | Electric aircraft / UAV |
| Adapter Rings | LPAR06E set |
