Description

About Product

The MN3508 belongs to T-MOTOR’s Navigator Series and is designed for stable propulsion across different aerial platforms. It features EZO bearings, flexible mounting holes and a 12N14P motor configuration. The KV580 variant can be paired with suitable T-MOTOR propellers and ESCs for UAV propulsion applications.

Key Features

• 580KV brushless motor
• Designed for 3–4S LiPo
• 35 mm stator diameter
• 12N14P configuration
• EZO bearings
• Flexible mounting-hole arrangement
• 600 mm motor cable
• Lightweight construction
• Suitable for multirotor, VTOL and fixed-wing UAVs
• Designed for stable and balanced propulsion


  Technical Specifications

  Specification	Details
  Brand	T-MOTOR
  Model	MN3508 KV580
  Series	Navigator
  Motor Type	Brushless UAV Motor
  KV Rating	580KV
  Configuration	12N14P
  Compatible Battery	3–4S LiPo
  Stator Diameter	35 mm
  Stator Height	8 mm
  Motor Dimensions	Ø41.8 × 26.5 mm
  Shaft Diameter	4 mm
  Cable Length	600 mm
  Cable Gauge	18 AWG
  Weight without Cable	82 g
  Weight with Cable	103 g
  Internal Resistance	110 mΩ
  Idle Current @ 10V	0.4 A
  Maximum Continuous Current	18 A / 180 s
