Description
About This Product
The 868ux/900ux to 8 Way Socket Cable is a breakout cable designed for RFD900ux and RFD868ux telemetry modems. It connects to the modem’s 10-pin JST locking interface and exposes the available modem signals through an 8-pin 0.1-inch (2.54mm) pitch socket.The cable provides a convenient way to access the modem’s communication and control connections without directly wiring into the modem connector. It can also be paired with an FTDI cable using the supplied pin header, making it useful for USB-to-serial configuration and development setups.
Features
- Designed for RFD900ux and RFD868ux modems
- Connects to the modem’s 10-pin JST locking connector
- 8-pin 0.1-inch / 2.54mm pitch socket
- Breaks out modem interface signals
- Excludes the modem’s external supply pins
- Supplied pin header enables FTDI cable connection
- Useful for modem configuration and serial communication
- Compact breakout solution for development and integration
- Suitable for UAV telemetry and RF communication systems
Technical Specifications
| Specification | Details |
|---|---|
| Product Type | Modem Breakout Cable |
| Brand | RFDesign (RFD) |
| Compatible Modems | RFD900ux / RFD868ux |
| Modem Connector | 10-pin JST locking connector |
| Breakout Connector | 8-pin socket |
| Socket Pitch | 0.1 inch / 2.54mm |
| External Supply Pins | Not included in 8-way breakout |
| FTDI Compatibility | Supported using supplied pin header |
| Application | Telemetry / Serial Communication |
| Cable Type | Breakout / Interface Cable |
Applications
- RFD900ux telemetry modem configuration
- RFD868ux telemetry systems
- FTDI-based modem connection
- UAV communication systems
- Serial telemetry development
- Radio modem integration
- Drone and fixed-wing UAV electronics
